Alien Higgs - 3 chips Protocol: EPCglobal Class 1 Gen 2 ISO/IEC 18000-6c Working frequency: 840~960MHz EPC capacity: 96 Bits User memory: 512 Bits TID: 32 Bits Access instruction: 32 Bits Inactivate instruction: 32 Bits Effective service life: ≥10 years Effective use: ≥10,000 times Read speed:≤0.05 seconds
Impinj Monaza 4 Protocol:EPCglobal Class 1 Gen 2 ISO/IEC 18000-6C Frequency:840~960MHz
型号
用户内存 (Bits)
EPC容量 (Bits)
流水号TID
True3DTM 天线技术
QTTM 技术
Monza 4D
32
128
√
√
Monza 4E
128
最高可至496
√
√
Monza 4U
512
128
√
√
Monza 4QT
512
128
√
√
√
NXP U CODE G2iL chip
Protocol: EPCglobal Class 1 Gen 2 ISO/IEC 18000-6c
Working frequency: 860~960MHz
EPC capacity: 128 Bits
User memory: 512 Bits
TID: 64 Bits (with 32 Bits unique serial number)
Features:
• product status label (PSF) : indicates whether the product has passed quality inspection or specified process inspection. The electronic security system (EAS) can quickly and reliably detect/identify stolen items. Since EAS systems, supply chain management (SCM), and inventory management only require the same label, cost can be effectively reduced. In addition, G2iL is used for database, and can also predict and manage replenishment.
• read protection: product information in EPC/TID memory is restricted to authorized access. It can effectively protect the confidential content in memory and avoid the troubles of retail owners in protecting privacy. Both features are backward compatible with UCODE G2X custom instructions.
